DN100 A516 배수 밸브가있는 도관 슬래브 게이트 밸브를 통해

DN100 도관 슬레이트 게이트 밸브를 통해 EN558.It 피깅 기능이 필요한 파이프 라인 애플리케이션에 이상적입니다.

  • 지불:

    30% when order confirmed, 70% before shipment
  • 제품 원산지:

    China
  • 색:

    Customization
  • 배송 포트:

    Shanghai, China
  • 리드 타임:

    30~60 days Ex Works after order confirmation
  • Material:

    A516
  • Method of Operation:

    Handwheel
지금 문의
제품 상세 정보

빠른 세부 사항

유형

게이트 밸브

공칭 직경

DN100

공칭 압력

PN63

구성

슬래브 유형; 통과 도관

연결

d 유형 플랜지

디자인 & 제조

EN558

끝에서 끝까지 차원

EN558.1

플랜지 치수

EN1092-1 디

테스트 & 검사

API598

바디 재질

A516

디스크 재료

A516

시트 재료

A105 + ENP + RPTFE

기온 범위

-29 ~ 121 ℃

미디어

물, 증기, 기름, etc

도관 플레이트 게이트 밸브를 통해 석유 및 가스 산업 액체 및 가스 응용 분야를위한 선택 where 신뢰할 수 있고 긴밀한 차단 누출을 방지하고 공정 오염 손실을 최소화하기 위해 필요합니다.

풍모

-화재 안전 레벨 : Mk

-온도. 레벨 : T3 ,

-누설 레벨 : EN12266A

-뒤로 좌석

-기본 금속 보조 부드러운 시트

-변경 가능 물건을 포장



기술 도면


증인 테스트


포장


특별 테스트

일반 테스트 외에도 (유압 및 공기 테스트) 할 수 있습니다 또한 인장 강도 시험, metallographic 테스트, 비산 배출 테스트, andNDE 테스트 (UT, RT, PT, MT) upon 고객 ' 특정 요청.



메시지를 남길

에 관심이 있다면 우리의 제품과한 자세한 내용을 알고 싶다면,메시지를 남겨주십시오 여기,우리가 응답할 것입니다 당신은 빨리 우리가 할 수 있습니다.

관련 상품
탄소강 슬래브 게이트 밸브
플랜지 도관 슬래브 게이트 밸브 dn200 pn64를 통해

din 표준에 따라 설계된 관통 도관 슬래브 게이트 밸브에는 파이프 라인 청소를위한 전환 구멍이 있습니다. pn64 병렬 디스크 게이트 밸브는 rf 플랜지와 핸드 휠이있는 탄소강으로 만들어집니다. 빠른 세부 사항 유형 평행   슬래브 게이트 밸브 공칭 직경 dn   200 공칭 압력 pn   64 구성 평행   슬래브 게이트 밸브, 전환 구멍 있음, 볼트 식 보닛, 탄성 시트 연결 플랜지 조작 핸드 휠   조작 바디 재료 탄소   강철 매질 물,   석유와 가스 유래 중국 디자인 기능1. 파렐 디스크선택을위한 2.soft 좌석 그리고 금속 좌석pigging와 더 적은 압력 강하를위한 3.full 구멍 디자인4. 화재 안전 설계5.self 구호 기능좌석과 줄기를위한 6.Grease 이음쇠7. 더블 블록 및 블리드 기능8. 배기 및 배수 포트9. 꽉 밀봉 성능 재료 부품 이름 재료 몸 & amp; 보닛 a216 wcb, cf8, cf8m, cf3,   cf3m 쐐기 합금강 (표면 경화   처리), 스테인리스 스틸 (공동 오버레이 포함) 줄기 합금강 (면   침식 방지 처리) 좌석 합금강 (표면 경화   처리, 베셋 f 플라스틱), 스틸 (공동 오버레이, 최고 f 플라스틱) 포장 ptfe O 링 nbr, p 밀봉 그리스 & emsp;

도관 게이트 밸브를 통해
도관 확장 게이트 밸브를 통해 18 인치 600lb api6d

도관 게이트 밸브를 통한 API 6d는 이중 확장 웨지, 금속 대 금속 시트 및 피깅을위한 전환 구멍으로 설계되었습니다. 밸브는 밀봉 성능이 우수하고 유동 저항이 적으며 일부 고체 또는 입자와 함께 사용하기에 적합합니다. 빠른 세부 사항 유형 문   판막 크기 18 인치 설계 압력 아니   600 구성 더블   쐐기, 완전 금속 시트, 전환 구멍 있음 연결 타입 rtj   플랜지 작업 유형 변속 장치   움직이는 바디 재료 wcb 쐐기 a105 + stl + enp 줄기 재료 17-4ph 시트 재료 a105 + stl + enp 디자인 코드 API 6D 대면 치수 저 같은   b16.10 연결 종료 저 같은   b16.5 압력 및 온도 저 같은   b16.34 매질 물,   석유와 가스 유래 중국

게이트 밸브
API 6D 스루 도관 게이트 밸브 소프트 시트 20인치 600LB

API 6D 스루 도관 게이트 밸브는 탄소강 WCB로 만든 600LB 플랜지 및 기어박스 연결.로 설계되었습니다., 20인치 게이트 밸브는 전환 구멍이 없는 부드러운 시트 설계를 가지고 있습니다..

클래스 150 플로팅 볼 밸브
알루미늄 청동 뜨 공 벨브 1 인치 150lb

1 인치 플로팅 타입 볼 밸브는 알루미늄 브론즈 c95800으로 제작되었습니다. 감소 된 보어 볼 밸브에는 레버 작동, rf 플랜지, 2 피스 타입 본체가 있습니다. 빠른 세부 사항 유형 볼 밸브 크기 1" 압력 아니 150 구성 떠 있는   볼, 2 피스 바디, 측면 입구, 보어 감소 연결 플랜지   종료 조작 지렛대   조작 신체   재료 알류미늄   청동 ASTM B148 C95800 미디어 w.o.g 볼 밸브에 사용 가능한 수정 공칭 압력 밸브 크기 -감소 된 포트 & amp; 풀 포트 -몸체, 볼, 스템, 시트, 패킹, 볼트 및 너트의 재질 밸브 작동 (레버, 기어 박스, 공압 또는 유압 또는 전기 액추에이터) 연결 유형 사용 가능한 확장 스템 맞춤형 코팅 및 포장 배수구 수정 dervos 포장 좋은 포장은 좋은 첫 인상을 의미합니다. 아래 두 개의 상자를 볼 때 어떻게 다르게 느끼는가? 그리고 당신은 왜 dervos에서 우리가 포장을 그렇게 중요하게 생각하는지 이유를 알 것입니다. dervos에서 우리는 1. 모든 밸브가 깨끗하고 건조합니다. 우리는 무엇을해야합니까? 포장하기 전에 밸브를 청소 녹슬지 않는 기름을 첨가하십시오 플랜지 커버 추가 납품에있는 벨브에 2.no 손상. 우리는 이것을 어떻게 달성합니까? 철 와이어로 밸브를 고정 부드러운 재료로 밸브를 분리하십시오. 합판을 가진 벨브를 층을 이루십시오 3.strong 상자 및 명확한 배송 표시

BS 1868 스윙 타입 체크 밸브
8 인치 스윙 체크 밸브 1500 lb WCB 플랜지 BBS BS 1868

8 인치 비 복귀 체크 밸브는 볼트 보닛 및 스윙 타입 디스크와 함께 bs 1868 설계 코드를 준수합니다. 플랜지 체크 밸브는 탄소강 a216 wcb로 만들어집니다. 디자인 기능1.bb : 볼트 보닛2. 스윙 형 디스크3. 보어 디자인 감소4. 우수한 유량5. 마찰 손실 최소화선택을위한 6.standard 손질 물자7. 요청에 따라 외부 또는 내부 힌지 핀 사용 가능요청에 따라 8.cylinder 및 카운터 무게 9. 베어 스템 및 액추에이터는 요청시 제공 가능 빠른 세부 사항 유형 검사   판막 크기 8 인치 설계 압력 아니   1500 년 구성 볼트   보닛, 스윙 타입 연결 높인   페이스 플랜지 디자인 및 제조 bs   1868 끝으로 종료 저 같은   b16.10 연결 저 같은   b16.5 압력 및   온도 저 같은   b16.34 테스트 & amp;   검사 API   598 바디 재료 탄소   강철 해당 온도 -29 ℃ ~ + 400 ℃ 미디어 w.o.g. 치수 클래스 1500 nps 에 2 2 1/2 삼 4 6 8 10 12 dn mm 50 65 80 100 150 200 250 300 l-l1(rf-bw) 에 14-1 / 2 16-1 / 2 18-1 / 2 21-1 / 2 27-3 / 4 32-3 / 4 39 44-1 / 2 mm 368 419 470 546 705 832 991 1130 l2(rtj) 에 14-5 / 8 16-5 / 8 18-5 / 8 21-5 / 8 28 33-1 / 8 39-3 / 8 45-1 / 8 mm 371 422 473 549 700 841 1000 1146 h(열다) 에 12-1 / 4 12-1 / 4 13 14 15-3 / 4 20-7 / 8 22-1 / 16 25-5 / 8 mm 310 310 330 355 400 530 560 650 wt(킬로그램) rf 69 93 140 232 490 990 1490 1970 년 bw 49 74 111 185 375 803 1250 1625

 연성 철 게이트 밸브
연성 철 게이트 밸브 비 상승 줄기 pn10 ggg50

연성 철 게이트 밸브에는 ggg50 바디 재질과 epdm 소프트 시트가 있습니다. 밸브는 비 상승 스템, rf 연결 및 수동 작동으로 설계되어 화수에 사용됩니다. 빠른 세부 사항 유형 문   판막 크기 dn300,   dn400 설계 압력 pn10 구성 비 상승   줄기, 연약한 좌석 연결 타입 플랜지 작업 유형 핸드 휠   조작 바디 재료 ggg50 트림 재료 줄기 2cr13, epdm 좌석 매질 물 유래 중국 정수압 시험 치수 확인 포장

플러그 밸브
1 인치 Class600 역 압력 균형 윤활 플러그 밸브 단조 강철, 전체 보어

빠른 세부 정보 유형 플러그 밸브 크기 1'' 디자인압력 600LB 건설 윤활 유형, 반전 유형, 압력 균형 유형, 연결 타입 FNPT 작업 레버 작동 디자인 코드 API6D 연결 종료 ASMB1.20.1 압력 & 온도 ASME B16.34 테스트 & 검사 API 598 화재 안전 API 6FA 본체 재질 A105 온도 범위 ≤80℃ 애플리케이션 물, 기름, 가스 특징 --신뢰할 수 있는 씰링 성능과 작은 토크; --풀 보어 --저배출 패킹; --화재 안전 설계; --선택적인 잠금 장치 기술 도면 치수 확인 증인 시험 포장 왜 Dervos를 파트너로 선택합니까? 원스톱 서비스 여기 Dervos에서는 전체 제품 목록을 통해 원스톱 서비스를 제공할 수 있습니다. 즉, 다양한 유형의 밸브에 대해 다양한 공급업체를 찾을 필요가 없으며 시간과 에너지를 확실히 절약할 수 있습니다. Dervos를 선택하기만 하면 완벽한 솔루션을 제공할 것입니다. 정시 배달 Dervos는 정시 납품의 높은 비율을 유지합니다. 우리가 그것을 달성할 수 있었던 이유는 무엇입니까? 우리 구매 팀은 주문을 매우 밀접하게 따릅니다. 또한 QC 및 영업 사원도 각 주문에 대한 모니터링 작업을 수행합니다. 엄격한 품질 관리 QC 팀의 모든 구성원은 경험이 풍부하고 전문적입니다. 각 주문에 대해 원자재, 제조 공정을 확인하고 쉘 및 씰에 대한 압력 테스트를 수행하고 어셈블리 도면에 따라 밸브 치수를 확인합니다. 마지막으로 도장과 포장을 검사합니다.

거르는 사람
8" 150LB 주강 Y형 스트레이너 RF CF3M ASME B16.34

8" 150LB 스트레이너는 ASME B16.34 표준에 따라 만들어집니다. 밸브 본체는 CF3M으로 만들어집니다. Y 유형의 구조적 특성을 가지고 있습니다. 연결 모드는 RF입니다.

다섯 개의 백성 중 하나
API6D 반전압 균형 잡힌 윤활 플러그 밸브 150LB

반전압 균형 잡힌 윤활 플러그 밸브 2inch150LB. 으로 제조 당 API6D,밸브에서 할 수있는 매니폴드 및 생산 서비스의 유,아스팔트 식물,다른 사람입니다.

다섯 개의 백성 중 하나
300 파운드 SS 비유적인 글로브 밸브 핸 RF

1-1/2inch 글로브 밸브,에 따라 설계되었 API623,폭탄을 가지고 있 모 몸 포물선 플러그의 최적화의 원활한 흐름다. 이 밸브는 스테인리스로 만들고 있는 수동 핸들과 운영 및 유지합니다.

스윙 체크 밸브
API 6D WCB RF 스윙 타입 체크 밸브 CL600 4 인치 6 인치

api6d 스윙 타입 체크 밸브 rf 연결 볼트 보닛 전체 기공 wcb 바디, wcb + 13cr 디스크, a105 + 13cr 시트 링, wcb 힌지. -29 ℃ ~ + 425 ℃에있는 적당한 온도 빠른 세부 사항 유형 스윙 체크 밸브 크기 4 인치 -6 인치 설계 압력 cl600 구성 bc, 스윙 타입 연결 타입 플랜지 작업 유형 - 바디 재료 wcb 디스크 재료 wcb + 13cr 힌지 재료 wcb 시트 재료 a105 + 13cr 디자인 코드 API 6D 대면 치수 asme b16.10 테스트 및 검사 API 598 압력 및 온도 asme b16.34 매질 물, 기름 및 가스 유래 중국

볼 밸브
API598 2" 150LB 플로팅 볼 밸브 RF 레버 ISO17292

2 "150LB 볼 밸브는 ISO17292 표준에 따라 만들어집니다. 밸브 본체는 B148 C95400으로 만들어졌습니다. 전체 흐름, 부동 볼, 화재 방지, 정전기 방지 및 비행 방지 밸브 스템의 구조적 특성을 가지고 있습니다. 작동 모드 는 레버이고 연결 모드는 RF입니다.
